RUiXU Battery | Lithi2-16 | 51.2V314Ah | 16kWh LiFePO4 Battery Energy Storage
RUiXU Battery | Lithi2-16 | 51.2V314Ah | 16kWh LiFePO4 Battery Energy Storage
Standard Included
- (1) RUiXU Lithi2-16
- (1) RJ45/CAT5e Patch Cable
- (1) Ground Cable
- (1) Set of parallel 1/0 AWG OP140 Cable
Lithi2-16
- Nominal voltage ：51.2V
- Nominal [email protected] ：314 Ah
- Min. [email protected]：314 Ah
- Nominal energy :16.07kWh
- Dimensions(W*D*H):924(with wheels)*543*250mm | 36.3(with wheels)*21.3*10inch
- Weight: ~145kg （320lb)
- Cycle life@80% DOD:≥9500 cycles
COMMUNICATIONS:
- Canbus: Victron, SMA, Studer Innotec, Sofar, Solark, Solis, Goodwe, Deye, Growatt, SAJ, LUXPOWER, Megarevo, INVT, Sermatec, TBB, MUST, Sunsynk, Schneider
- RS485: MPP, Voltronic, RCT, Alpha outback
ON-BOARD LCD TOUCH SCREEN
5-inch capacitive touch screen provides battery information and allows easy and intuitive adjustment of battery settings.
PERFLUOROHEXANE MODULE
A perfluorohexane module improves fire protection inside the battery pack to both electrical lines and cells.
QUICK PLUGS
Quick plugs provide 250A (continuous) overcurrent capacity, easy tool-less connection, long-term anti-loosening and heating protection.
FUMA WHEELS AND WALL MOUNTED FIXATION
Four concealed heavy-duty Fuma wheels facilitate movement of the battery without detracting from the elegant design. An anti-tipping mount on the back anchors the battery to the wall.
BATTERY MAINTENANCE AND INSPECTION PORT
An inspection port on the side of the battery provides access to the BMS and fuse for ease of maintenance.
ALL POLE PROTECTION
All-pole, dual protection through fuse (negative terminal) and micro circuit breaker (positive terminal).
INTELLIGENT BALANCING
A double equilibrium approach achieves efficient cell balancing by calculating capacity differences between battery cells from charging-process data and by extending the balancing time, improving the efficiency and reliability compared to general passive and active balancing modes.
SELF-HEATING FEATURE
Keeping your battery charged in cold temperatures .
ELECTRO-COATING BATTERY CASE FOR OUTDOOR USE
Electro-coating (electrophoresis) of the battery enclosure provides excellent rust prevention for outdoor use.The electrophoretic coating process is widely used in the production of automotive body shells
Warranty
- 10 years covering product replacement or repair (Click here for more details)
Resources:
