MRCOOL DIY 12,000 BTU Mini Split System - Easy Installation & Comfort

Product image 1
1 / 6
+1

MRCOOL DIY 12,000 BTU Mini Split System - Easy Installation & Comfort

MRCOOL DIY® 5th Gen EasyPro 12,000 BTU Single Zone Mini Split Complete System 115V with 16 ft. DIY Quick Connect Line Set and DIYPRO Cable, EZPRO-12-HP-11516D-O

The MRCOOL® Easy Pro™ Mini-Split System delivers powerful, energy-efficient heating and cooling for spaces up to 550 sq. ft.- all with a simple DIY installation. This complete system includes a quiet, WiFi-enabled indoor air handler and a rugged outdoor condenser. Whether for a bedroom, office, or tech space like a server room, the Easy Pro™ system offers smart control, year-round performance, and peace of mind - without breaking the bank.

  • DIY Installation Made Simple: Comes with a 16' pre-charged Fast Connection® line set for easy homeowner installation - no HVAC technician required.
  • Smart Home Integration: Built-in WiFi with MRCOOL® Smart HVAC Controller® app support, plus full compatibility with Google Assistant and Amazon Alexa.
  • Personalized Comfort Control: Includes a remote with Follow Me® technology that adjusts temperature based on your location in the room.
  • Energy-Efficient Performance: Features a SEER2 rating of 19.5 and HSPF2-4 of 9.3, providing cost-effective heating and cooling all year long.
  • Quiet Operation: Runs at just 54 dB(A), making it ideal for bedrooms, offices, and other quiet spaces.
  • Low Ambient Cooling: Delivers consistent performance even in outdoor temperatures as low as 5°F—perfect for server rooms or greenhouses.
  • Durable, Weather-Resistant Design: Gold Fin® condenser coating offers long-term corrosion resistance, ideal for coastal environments.
  • Clean, Healthy Air: Active Clean Technology keeps the indoor unit fresh and filters easy to maintain for better indoor air quality.
  • Eco-Conscious & Certified: Uses R-454B refrigerant and meets AHRI, NEEP ccASHP, and CEE Tier 1 - North certification standards.
  • Warranty Protection: Includes a 2-year parts warranty and a 1-year compressor warranty upon registration for peace of mind.

SPECIFICATIONS & DIMENSIONS

Dimensions

Condenser Dimensions
 28.35 W" x 10.63 D" x 19.49 H"
Air Handler Dimensions
31.57 W" x 7.87 D" x 11.61 H"
Condenser Weight
31.57 W" x 7.87 D" x 11.61 H"
Air Handler Weight
54.89 lbs

Capacity & Performance

Zone Capacity
1
Cooling Capacity
12,000 BTU
Outdoor Operating Temperature (Cooling)
5°F - 122°F
EER2
9
SEER2
19.5
Heating Capacity
12,000 BTU
Outdoor Operating Temperature (Heating)
13°F - 75°F
HSPF2-4
9.3
HSPF2-5
7
Coverage Area
Up to 550 sq ft.
Outdoor Noise Level
54 dB(A)
Indoor Noise Level (Hi/Mi/Lo)
44.5/35/17.5 dB(A)

Electrical Requirements

Voltage
 115V
Phase
1
Cycle
60 Hz
Max Fuse Breaker
20A
Min Circuit Ampacity
19.5A

Refrigerant & Piping

Refrigerant Type
 R-454B
Refrigerant Volume
21.52 oz
Liquid Line Size
1/4"
Suction Line Size
3/8"
Max Line Set Length
82 ft.

Features

Modes
 Auto Mode: Automatically selects heating or cooling based on the room's temperature.
Cool Mode: Lowers the room temperature to your desired setting.
Heat Mode: Raises the room temperature to your desired setting.
Fan-Only Mode: Circulates air without heating or cooling.
Dry Mode (Dehumidification): Reduces humidity levels in the room.
Sleep Mode: Gradually adjusts temperature settings for comfortable sleep and energy savings.
Inverter
DC
Compressor Type
Rotary
Fan Only Option
Yes
Quiet Mode
Yes
Auto Cool
Yes
Wifi Compatibility
Yes
App Compatibility
Yes
Works with IOS
Yes
Works with Android
Yes
Remote Control Included
Yes

Certifications & Warranty

Certifications
 UL Listed, CSA Listed, ETL Listed, AHRI Certified
Warranty
2 Year Parts / 1 Year Compressor

Installation & Guides

MRCOOL DIY® 5th Gen EasyPro 12,000 BTU Single Zone Mini Split Complete System 115V with 16 ft. DIY Quick Connect Line Set and DIYPRO Cable, EZPRO-12-HP-11516D-O

The MRCOOL® Easy Pro™ Mini-Split System delivers powerful, energy-efficient heating and cooling for spaces up to 550 sq. ft.- all with a simple DIY installation. This complete system includes a quiet, WiFi-enabled indoor air handler and a rugged outdoor condenser. Whether for a bedroom, office, or tech space like a server room, the Easy Pro™ system offers smart control, year-round performance, and peace of mind - without breaking the bank.

  • DIY Installation Made Simple: Comes with a 16' pre-charged Fast Connection® line set for easy homeowner installation - no HVAC technician required.
  • Smart Home Integration: Built-in WiFi with MRCOOL® Smart HVAC Controller® app support, plus full compatibility with Google Assistant and Amazon Alexa.
  • Personalized Comfort Control: Includes a remote with Follow Me® technology that adjusts temperature based on your location in the room.
  • Energy-Efficient Performance: Features a SEER2 rating of 19.5 and HSPF2-4 of 9.3, providing cost-effective heating and cooling all year long.
  • Quiet Operation: Runs at just 54 dB(A), making it ideal for bedrooms, offices, and other quiet spaces.
  • Low Ambient Cooling: Delivers consistent performance even in outdoor temperatures as low as 5°F—perfect for server rooms or greenhouses.
  • Durable, Weather-Resistant Design: Gold Fin® condenser coating offers long-term corrosion resistance, ideal for coastal environments.
  • Clean, Healthy Air: Active Clean Technology keeps the indoor unit fresh and filters easy to maintain for better indoor air quality.
  • Eco-Conscious & Certified: Uses R-454B refrigerant and meets AHRI, NEEP ccASHP, and CEE Tier 1 - North certification standards.
  • Warranty Protection: Includes a 2-year parts warranty and a 1-year compressor warranty upon registration for peace of mind.

SPECIFICATIONS & DIMENSIONS

Dimensions

Condenser Dimensions
 28.35 W" x 10.63 D" x 19.49 H"
Air Handler Dimensions
31.57 W" x 7.87 D" x 11.61 H"
Condenser Weight
31.57 W" x 7.87 D" x 11.61 H"
Air Handler Weight
54.89 lbs

Capacity & Performance

Zone Capacity
1
Cooling Capacity
12,000 BTU
Outdoor Operating Temperature (Cooling)
5°F - 122°F
EER2
9
SEER2
19.5
Heating Capacity
12,000 BTU
Outdoor Operating Temperature (Heating)
13°F - 75°F
HSPF2-4
9.3
HSPF2-5
7
Coverage Area
Up to 550 sq ft.
Outdoor Noise Level
54 dB(A)
Indoor Noise Level (Hi/Mi/Lo)
44.5/35/17.5 dB(A)

Electrical Requirements

Voltage
 115V
Phase
1
Cycle
60 Hz
Max Fuse Breaker
20A
Min Circuit Ampacity
19.5A

Refrigerant & Piping

Refrigerant Type
 R-454B
Refrigerant Volume
21.52 oz
Liquid Line Size
1/4"
Suction Line Size
3/8"
Max Line Set Length
82 ft.

Features

Modes
 Auto Mode: Automatically selects heating or cooling based on the room's temperature.
Cool Mode: Lowers the room temperature to your desired setting.
Heat Mode: Raises the room temperature to your desired setting.
Fan-Only Mode: Circulates air without heating or cooling.
Dry Mode (Dehumidification): Reduces humidity levels in the room.
Sleep Mode: Gradually adjusts temperature settings for comfortable sleep and energy savings.
Inverter
DC
Compressor Type
Rotary
Fan Only Option
Yes
Quiet Mode
Yes
Auto Cool
Yes
Wifi Compatibility
Yes
App Compatibility
Yes
Works with IOS
Yes
Works with Android
Yes
Remote Control Included
Yes

Certifications & Warranty

Certifications
 UL Listed, CSA Listed, ETL Listed, AHRI Certified
Warranty
2 Year Parts / 1 Year Compressor

Installation & Guides
