Daikin DKN Residential Cloud Wi-Fi Adaptor for Ductless Systems (S21) - AZAI6WSCDKB
Daikin DKN Residential Cloud Wi-Fi Adaptor for Ductless Systems (S21) - AZAI6WSCDKB
Enable remote control of Daikin Single and Multi-Zone indoor units through an iOS/Android App with the DKN Residential Wi-Fi Adaptor for Ductless Systems (AZAI6WSCDKB). Utilizing the same smartphone app as the DKN Cloud Wi-Fi Adaptor for VRV (AZAI6WSCDKA), users will enjoy peace of mind and quick access to monitor and control all of their indoor units (S21 and P1P2) from one app.
With the app, the adaptor provides: remote control and monitoring of indoor units’ On/Off, mode, set-point, fan speed, louver position, room temperature, and error alert status from an iOS or Android smartphone. Voice control is also possible through Google Assistant and Amazon Alexa. It also provides Cloud API and Modbus® connection for integration with Home Automation Systems.
Features:
- Control and monitor indoor unit’s on/off, mode, set-point, fan speed, louver position, room temperature, and error status
- 7 days schedule
- Leveled user authority: Basic/Advanced
- Unlimited indoor units can be added to one account
- Control indoor units as a group
System Overview
The adaptor is connected to indoor units directly and can be used together with the handheld remote for the indoor unit
Smart Home Integration
This adaptor provides two approaches to integrate with a Home Automation System
Model Compatibility
Compatible with Single-Zone and Multi-Zone system indoor unit models: CDXS, CTXS*, FDXS, FTK*, FTKB*, FTX*, FTXB* FTXG, FTXR, FTXS, FVXS, FTXM
The following indoor units require an additional interface adaptor (ordered separately) to provide the S21 connection:
| Indoor Unit Models | Required Interface Adaptor |
| FTX09NMVJU(A), FTX12NMVJU(A), FTX09WMVJU9, FTX12WMVJU9 | KRP067A41E |
| FTX15NMVJU(A), FTX15WMVJU9 | KRP980B2E |
| FTXM09VVJU, FTXM12VVJU, FTXM18VVJU, FTXM24VVJU, FTXM09WVJU9, FTXM12WVJU9, FTXM18WVJU9, FTXM24WVJU9 | KER087A41 |
*FTK_AXVJU, FTKB_AXVJU, FTX_AXVJU, FTXB_AXVJU and CTX_AXVJU units are not compatible.
Specifications:
| Brand | Daikin |
| Model | AZAI6WSCDKB |
| Warranty | 1-Year |
| Unit Type | DKN Residential Cloud Wi-Fi Adaptor for Single- and Multi-Zone System (S21) |
| Maximum Indoor Units | 1 |
| Total Wiring Length | 8.2ft (2.5m) |
| Dimensions | 3.6 in x 3.15 in x 1.15 in (92mm x 80mm x 29 mm) |
| Weight | 0.28lbs (130 g) |
| Communication Protocol | S21 |
| Storage Temperature | -4°F to 158°F (-20 °C to 70 °C) |
| Operation Temperature | 32°F to 122°F (0 °C to 50 °C) |
| Operation Humidity | 5% to 90% (non-condensing) |
| Communication |
|
| Modbus RS485 communication baud rate | 19200 bps (configurable) |
|
Power Supply |
|
| Resources |
