BigBattery 24V EAGLE 2 – LiFePO4 – 64Ah – 1.63kWh

Introducing BigBattery’s all-new 24V 1.63 kWh LiFePO4 EAGLE 2. This battery embodies the reliability and durability you’ve come to expect from BigBattery solutions, packing Tier 1 LFP cells in a compact, GC2 form factor. This energy-dense design allows for effortless installations in your RVs, camper vans, scissor lifts, or other industrial equipment, and the EAGLE 2 serves as a mirror-image replacement for any stock T-105 lead-acid battery.

But the EAGLE 2 provides so much more than efficient, long-lasting lithium power storage. This battery comes standard with advanced features that enhance the safety and visibility of your power. Not only does the EAGLE 2 come equipped with a LED capacity meter on the top of the unit, but also supports CANBus communication protocols, so you can always monitor the status and performance of your battery system. Plus, the EAGLE 2 is IP67-rated for comprehensive protection against dust, water, and other contaminants while you’re cruising around the campsite or warehouse.

But that’s not all. The EAGLE 2 was designed to support your applications through every season. Whether you’re going boondocking in the heat of summer, or working at the warehouse or job site in the dead of winter, the EAGLE 2’s advanced BMS supports a wide temperature operating range, and a self-heating function ensures that you never have to put your vacation or work day on pause due to unreliable power. Quit worrying about your power and get back to working hard and playing harder when you equip your vehicle with the all-new EAGLE 2 from BigBattery. Shop the 24V EAGLE 2 & EAGLE 2 Kits today.

Warranty:

• 12 Year Warranty

What's Included:

• 1 x Eagle 2 Carrying Handle

• 1 x Eagle 2 CAN Comm Cable

• 1 x Parallel CAN Comm Cable

• 2 x M8 Nuts & Screws

Benefits:

• IP67 Protection Rating
• Automatic Self-Heating
• Canbus Communications
• Simple Installation

Designed for 24V Applications:

• T-105 Exact Replacement

• Light Industrial Equipment
• Floor Sweepers
• Floor Scrubbers
• Pallet Jacks

• Scissor Lifts

• Light Towers
• Class A, B, & C RVs
• Camper Vans
• Emergency Backup


Videos:

24V & 48V EAGLE 2 - Upgraded Mobile Power | LiFePO4 Batteries



24V EAGLE 2 - Product Unboxing

Tech Specs:

Brand	BigBattery
SKU	FEAGL-24016-G2-0CH
GTIN-12 (U.P.C.)	850061252197
System Voltage	24V
Nominal Voltage	25.6V
Chemistry	LiFePO4
kWh Capacity	1.63kWh
Ah Capacity	64Ah
Charging Voltage Range	27.8 - 29V
Max Charge Voltage	29.2V
Operating Voltage Range	24 - 28.8V
Suggested Low Voltage Cutoff	24 - 25.4V
BMS Cutoff Range	21 - 23.5V
Cell Configuration	8S
Max Continuous Discharge Current	100A
Max Continuous Power	2560W
Max Discharge Peak Current	200A (Max 5 seconds)
Max Charge Current	64A
Charge Temperature Range	-4°F - 131°F (-20°C - 55°C)
Discharge Temperature Range	-4°F - 140°F (-20°C - 60°C)
Optimal Discharge Temperature Range	59°F - 95°F (15°C - 35°C)
Storage Temperature Range	23°F - 95°F (-5°C - 35°C) (Max 3 months) 32°F - 77°F (0°C - 25°C) (Max 12 months)
Weight	38 lb (17.2 kg)
Depth	7.1 in (180 mm)
Width	10.2 in (260 mm)
Height	10.8 in (274 mm)
Max Connections	Up to (10) Parallel
Protection Rating	IP67 / NEMA 6
Communications	CANBus
Self-Heating	Yes
Spec Sheet	Spec Sheet
User Manual	User Manual
CE Certificate	CE Certificate
EMC Certificate	EMC Certificate
UN38.3 Certificate	UN38.3 Certificate
