Daikin MXM R-32 Standard Multi (5-Port) — 5-Zone Configuration

Bring room-by-room comfort to more spaces with one compact, inverter-driven outdoor unit—a sustainable way to heat and cool without ductwork.

• Inverter-driven compressor: Inverter-driven swing compressor for steady comfort and energy-smart operation.
• True zoning: Set different temperatures in different rooms—condition only the spaces you use.
• Sustainable refrigerant: Uses R‑32 refrigerant for a lower global warming potential option compared to R‑410A, supporting a smaller footprint.
• Comfort features: Connect 2–5 indoor units, Night Quiet Mode, Automatic Defrost, Quick Warming Function.
• Quiet performance: Outdoor sound pressure level as low as 55 dBA (cool) / 57 dBA (heat).

This system includes

Component	Qty	Model	Notes
Outdoor Unit	1	5MXM48AVJU9	Multi-zone ductless heat pump outdoor unit
Indoor Unit	3	FTXV09AVJU9	Wall-mounted indoor unit • Rated cooling: 9,000 BTU/h
Indoor Unit	2	FTXV15AVJU9	Wall-mounted indoor unit • Rated cooling: 15,000 BTU/h

Outdoor unit specifications — 5MXM48AVJU9

• Rated cooling: 46,000 BTU/h
• Rated heating: 48,500 BTU/h
• Efficiency (outdoor unit): 20.0 SEER2 • 10.0 EER2 • 9.5 HSPF2
• Electrical: 208–230V, 1‑phase, 60Hz
• Minimum circuit / max fuse: 38.1A / 40A max fuse
• Operating range: Cooling 14°F–115°F • Heating 5°F–75°F
• Max total piping length: 262 ft
• Factory charge: Pre-charged to 131 ft

Warranty: 12-year residential limited parts and compressor warranty with online registration; 5-year limited parts warranty for commercial applications.

Controls: Each indoor unit includes a handheld controller, and many Daikin systems can be paired with connected controls to help you manage comfort and efficiency.

Perfecting the air means comfort with conscience: inverter technology helps reduce temperature swings and energy use, while R‑32 supports a lower‑GWP refrigerant strategy.
